C13ENTM77.10
3260.008 TEMPERATURE REGULATOR
| Item | Part number | Description |
|---|---|---|
| 1 | 8032185 | THERMOSTAT ASSY |
| 2 | 8032186 | FLAT ENGINE GASKET |
| 3 | 8032184 | FLAT ENGINE GASKET |
| 4 | 16606524 | HEXAGON BOLT M8X70 MM |
| 5 | 16606824 | HEXAGON BOLT M8X100 MM |
| 6 | 17089474 | SPRING WASHER Ø8X16 MM SP=1,4 MM |
| 7 | 8032716 | WATER MANIFOLD ASSY |
| 8 | 16607124 | HEXAGON BOLT M8X1,25X170 MM |
| 9 | 16607024 | HEXAGON BOLT M8X120 MM |
| 10 | 8032183 | SPACING BAR |
| 11 | 17290581 | O-RING Ø72,63X3,53 MM |
| 12 | 8034352 | PLUG |
| 13 | 8041871 | THREADED UNION |
| 14 | 99489017 | SEAL GASKET Ø12X20 MM SP=1,5 MM |
| 15 | 500304562 | BREATHER PLUG |
