C78ENTM50.10
A40050028/2 GAS-WATER MIXER WITH STERN OUTLET
Item | Part number | Description |
---|---|---|
1 | 8032238 | PIPE |
2 | 17764993 | CLIP Ø50/70 MM |
3 | 8019908 | HOSE |
4 | 4787181 | SUPPORT |
5 | 17816214 | SPACER Ø10X8,5X18 MM |
6 | 8113295 | CLAMP Ø50 MM |
7 | 8113296 | CLAMP Ø50 MM |
8 | 1366290 | RUBBER LUG |
9 | 16605624 | HEXAGON BOLT M8X25 MM (8.8) |
10 | 17089474 | SPRING WASHER Ø8X16 MM SP=1,4 MM |
