| Item |
Part number |
Description |
|
1 |
504373407 |
HYDRAULIC CYLINDER |
|
2 |
504382791 |
SENSOR |
|
3 |
504130662 |
VALVE |
|
4 |
504253853 |
SPACING BAR |
|
5 |
16586825 |
HEXAGON BOLT M8X1.25X45 MM |
|
6 |
504345093 |
FUEL LINE |
|
7 |
504345104 |
PIPE SOCKET |
|
8 |
504126981 |
FUEL LINE |
|
9 |
504126982 |
FUEL LINE |
|
10 |
504126983 |
FUEL LINE |
|
11 |
504345222 |
FUEL LINE |
|
12 |
504126985 |
FUEL LINE |
|
13 |
504126986 |
FUEL LINE |
|
14 |
504126984 |
FUEL LINE |
|
15 |
504345096 |
SCREW CONNECTOR |
|
16 |
504236628 |
FASTENING BRACKET |
|
17 |
504235264 |
FASTENING BRACKET |
|
18 |
16707034 |
CYLIND-HEAD SCREW M8X16 MM |
|
19 |
16585870 |
HEXAGON BOLT M6X20 |
|
20 |
99489016 |
SEAL GASKET Ø10X17 MM SP =1,5 |
|
21 |
504188076 |
HIGH PRESSURE PUMP |
|
22 |
504358313 |
FASTENING BRACKET |
|
24 |
16586225 |
HEXAGON BOLT M8X1,25X16 MM |
|
25 |
504312745 |
FASTENING BRACKET |
|
26 |
17095914 |
WASHER |
|
27 |
16674034 |
HEXAGON BOLT M8X40 MM |
|
28 |
504327363 |
FUEL LINE |
|
29 |
504130644 |
GEAR |
