| Item |
Part number |
Description |
|
1 |
8036502 |
WATER RADIATOR ASSY |
|
2 |
17765091 |
CLIP Ø60/80 MM |
|
3 |
98421391 |
RUBBER SLEEVE [UP TO 30-11-07] |
|
4 |
8049678 |
RUBBER SLEEVE [FROM 01-12-07] |
|
5 |
18088293 |
CLIP Ø12/20 MM |
|
6 |
8042565 |
WATER PIPE |
|
7 |
8019397 |
RETAINER |
|
8 |
16605624 |
HEXAGON BOLT M8X25 MM (8.8) |
|
9 |
741571 |
SPACING BAR Ø10X17 MM SP=2,3 |
|
10 |
17091074 |
WASHER Ø12X24X2,8 MM |
|
11 |
17038425 |
HEXAGON NUT M12 (8) |
|
12 |
8043420 |
TIE ROD |
|
13 |
741570 |
WASHER Ø10X17 MM SP=2,3 |
|
14 |
17769491 |
CLIP |
|
15 |
741569 |
RUBBER LUG |
|
16 |
5801638818 |
AIR PIPE/DUCT |
|
17 |
17284681 |
O-RING Ø61,6 MM SP=2,62 MM |
|
18 |
61318365 |
AIR PIPE/DUCT |
|
19 |
8050418 |
AIR PIPE/DUCT |
|
20 |
42088612 |
WATER HOSE |
|
21 |
4864082 |
BANJO BOLT M12X1,5X25 MM |
|
22 |
4800661 |
CLIP Ø 75 mm. |
|
23 |
18223480 |
HOSE |
|
24 |
4802434 |
THREADED UNION M12X1,5 |
|
25 |
98404884 |
SWIVEL COUPLING |
|
26 |
4858607 |
WASHER Ø12X17 MM SP=1,5 MM |
