F1AE0481F*A101
0710.247 INTAKE MANIFOLD
Item | Part number | Description |
---|---|---|
1 | 504072063 | INTAKE ELBOW |
2 | 16729324 | STUD M8X12X20 MM |
3 | 504084278 | INTAKE ELBOW GASK. |
4 | 504099669 | VALVE HOUSING |
5 | 504245257 | SENSOR AIR PRESS. & TEMPER. |
6 | 18137824 | HEXAGON BOLT M6X16 MM |
7 | 16674634 | HEXAGON BOLT M8X60 MM |
8 | 16673735 | HEXAGON BOLT M8X25 MM |
9 | 16592225 | HEXAGON BOLT M8X55 MM |
10 | 504037859 | INTAKE ELBOW GASK. |
