F1CE0481B*A001
0450.217 ENGINE BREATHERS
| Item | Part number | Description |
|---|---|---|
| 1 | 504089127 | BREATHER ASSY |
| 2 | 504050244 | SHAFT SEAL |
| 3 | 17291281 | O-RING Ø94,84 MM SP=3,53 MM |
| 4 | 16585825 | HEXAGON BOLT M6X20 MM |
| 5 | 16867073 | SPRING LOCKWASHER |
| 6 | 504075145 | AIR CLEANER |
| 7 | 504084336 | BREATHER PIPE |
| 8 | 504092840 | RUBBER SLEEVE |
| 9 | 18088492 | CLIP M20-32 |
| 10 | 11500324 | STUD M6X9 MM [FROM # 344848] |
| 11 | 17044721 | HEXAGON NUT M8X1,25 |
