F1CE0486A*A001
0450.223 ENGINE BREATHERS

Iveco/FPT ENGINE BREATHERS

Item Part number Description
1 504089127 BREATHER ASSY
2 504050244 SHAFT SEAL
3 17291281 O-RING Ø94,84 MM SP=3,53 MM
4 16585825 HEXAGON BOLT M6X20 MM
5 16867073 SPRING LOCKWASHER
6 504075145 AIR CLEANER
7 11500324 STUD M6X9 MM [FROM # 344848]
8 17044721 HEXAGON NUT M8X1,25
