F1CE3481F*D013
4000.028 GENERATOR
| Item | Part number | Description |
|---|---|---|
| 1 | 16673735 | HEXAGON BOLT M8X25 MM |
| 2 | 16673835 | HEXAGON BOLT M8X30 MM |
| 3 | 16586825 | HEXAGON BOLT M8X1.25X45 MM |
| 4 | 16587125 | HEXAGON BOLT M10X25 MM |
| 5 | 16676834 | HEXAGON BOLT M10X70 MM |
| 6 | 504371324 | GENERATOR SUPPORT |
| 7 | 500371139 | DOWEL PIN |
| 8 | 504349084 | DOWEL PIN |
