| Item |
Part number |
Description |
|
1 |
504021866 |
CYLINDER HEAD ASSY |
|
2 |
99476929 |
NOZZLE HOLDER SEAT |
|
3 |
17279081 |
O-RING Ø26,7 MM SP=1,7 MM |
|
4 |
500390993 |
VALVE GUIDE INTAKE |
|
5 |
500390864 |
VALVE GUIDE +0,2 INTAKE |
|
6 |
500390866 |
VALVE GUIDE +0,4 INTAKE |
|
7 |
16992411 |
THREADED PLUG M16X1,5 |
|
8 |
500390994 |
VALVE GUIDE EXHAUST |
|
9 |
500390860 |
VALVE GUIDE +0,2 EXHAUST |
|
10 |
500390861 |
VALVE GUIDE +0,4 EXHAUST |
|
11 |
500340761 |
LOCK PLUG ASSY |
|
12 |
99450511 |
VALVE SEAT STD. INTAKE |
|
13 |
504020517 |
VALVE SEAT +0.20 INTAKE |
|
14 |
99450512 |
VALVE SEAT STD. EXHAUST |
|
15 |
504020515 |
VALVE SEAT +0.20 EXHAUST |
|
16 |
504003914 |
BUSH EXHAUST |
|
17 |
504003915 |
BUSH |
|
18 |
98472271 |
THREADED PLUG |
|
19 |
500310146 |
THREADED PLUG |
|
20 |
99430692 |
THREADED PLUG 1/2'' |
|
21 |
16991370 |
LOCK PLUG Ø45 MM |
|
22 |
16990870 |
LOCK PLUG Ø28 MM |
|
23 |
16990570 |
LOCK PLUG Ø20 MM |
|
24 |
17257074 |
DOWEL PIN Ø6X18 MM |
|
25 |
93162429 |
ADHESIVE/STICKER LOCTITE |
|
26 |
500355778 |
INLET VALVE |
|
27 |
500355780 |
EXHAUST VALVE |
|
28 |
99474123 |
SPRING CAP |
|
29 |
40101874 |
SHAFT SEAL |
|
30 |
98475711 |
ENGINE VALV.SPRING |
|
31 |
98473050 |
TAPPET |
|
32 |
14196370 |
VALVE CONE Ø9,82 MM |
|
33 |
41031569 |
THREADED UNION M16X1,5 - M18X1,5 MM" |
|
34 |
99489019 |
WASHER Ø16X24 MM SP=1,5 MM |
|
35 |
17277981 |
O-RING 1,78x9,25 |
|
36 |
504001460 |
SPACING BAR |
|
37 |
500376911 |
RETAINING SPRING |
|
38 |
16707134 |
SOCKET-HEAD SCREW M8X20 MM |
|
39 |
16586224 |
HEXAGON BOLT M8X1,25X16 MM |
|
40 |
504002605 |
VALVE BRIDGE |
|
41 |
98495527 |
HEXAGON BOLT |
|
42 |
98495528 |
HEXAGON BOLT |
|
43 |
17275510 |
DOWEL PIN Ø10 MM |
|
44 |
504007514 |
CYL.HEAD GASKET |
