F3CE0684B*E005
1712.015 SENSORS

Iveco/FPT SENSORS

Item Part number Description
1 98472271 THREADED PLUG
2 99489018 SEAL GASKET Ø14X22 MM SP=1,5 MM
3 500346074 TRANSMITTER Pressure
4 17277881 O-RING Ø7,65 MM SP=1,78 MM
5 504084571 THREADED PLUG
6 16992415 THREADED PLUG M16X1,5
7 99489019 WASHER Ø16X24 MM SP=1,5 MM
8 16887515 THREADED PLUG
9 99489017 SEAL GASKET Ø12X20 MM SP=1,5 MM
10 16992311 LOCK PLUG M14X1,5
