F4AE0481C*C103
1405.008 HYDRAUL. ACCUMULATOR
Item | Part number | Description |
---|---|---|
1 | 504046311 | HYDRAULIC CYLINDER ASSY |
2 | 4899828 | THREADED UNION |
3 | 16508360 | WASHER 18x22x1,5 |
4 | 4899804 | VALVE |
5 | 504053982 | SENSOR |
6 | 504048154 | FUEL LINE |
7 | 504048155 | FUEL LINE |
8 | 504053762 | FUEL LINE |
9 | 16586225 | HEXAGON BOLT M8X1,25X16 MM |
10 | 4898270 | SCREW |
11 | 4899888 | HEXAGON BOLT M8X105 MM |
