F4AE0682C*C151
1405.001 HYDRAUL. ACCUMULATOR
| Item | Part number | Description |
|---|---|---|
| 1 | 4893177 | HYDRAULIC CYLINDER ASSY |
| 2 | 4899828 | THREADED UNION |
| 3 | 16508360 | WASHER 18x22x1,5 |
| 4 | 4899804 | VALVE |
| 5 | 4897501 | SENSOR ASSY [UP TO: 189668] |
| 6 | 500372236 | WASHER |
| 7 | 4898654 | VALVE |
| 8 | 504036540 | FUEL LINE |
| 9 | 504036539 | FUEL LINE |
| 10 | 4897063 | FUEL LINE ASSY |
| 11 | 4897270 | FASTENING BRACKET |
| 12 | 4897272 | FASTENING BRACKET |
| 13 | 4892980 | SCREW |
| 14 | 4898270 | SCREW |
| 15 | 4899872 | FASTENING BRACKET Ø6 MM |
