F4CE0454A*D607
3230.048 WATER PIPE

Iveco/FPT WATER PIPE

Item Part number Description
1 4899144 HEXAGON BOLT M10X1,5X50 MM
2 504062710 WASHER
3 4895990 GENERATOR SUPPORT
4 2830894 DOWEL PIN
5 16993311 THREADED PLUG M18X1,5
6 99489020 SEAL GASKET Ø18X26 MM SP=1,5 MM
7 2830622 HEXAGON BOLT
