F4CE0454C*D601
1050.008 ADDITIONAL MASSES
Item | Part number | Description |
---|---|---|
1 | 504088120 | SUPPORT ASSY |
2 | 4897123 | WASHER |
3 | 8093883 | BUSH ASSY |
4 | 4897048 | GEAR |
5 | 4896947 | GEAR |
6 | 4895586 | HEXAGON BOLT |
7 | 2830433 | SOCKET-HEAD SCREW |
8 | 2831031 | SHAFT |
9 | 504088119 | SHAFT |
10 | 2831300 | SUPPORT |
11 | 16866473 | SPRING LOCKWASHER |
12 | 4899109 | HEXAGON BOLT M10X1,5X80 MM |
13 | 4897934 | HEXAGON BOLT |
