F4GE9484A*J103
1405.021 HYDRAUL. ACCUMULATOR
| Item | Part number | Description |
|---|---|---|
| 1 | 504091065 | HYDRAULIC CYLINDER |
| 2 | 504053874 | HEXAGON BOLT |
| 3 | 4899020 | HEXAGON BOLT |
| 4 | 504088436 | VALVE ASSY |
| 5 | 504123163 | SENSOR |
| 6 | 504091558 | FUEL LINE |
| 7 | 504090756 | FUEL LINE |
| 8 | 504090755 | FUEL LINE |
| 9 | 4896884 | HEXAGON BOLT |
| 10 | 13605711 | SPACER Ø8,5x18 MM |
| 11 | 42553494 | O-RING |
