F4HE0684F*D100
2712.011 OIL DIPSTICK PIPE [FROM # 148475] [FROM # 148475]
Item | Part number | Description |
---|---|---|
1 | 500301568 | OIL FILLER PLUG ASSY |
2 | 17295480 | O-RING 5,33x37,46 |
3 | 504087621 | OIL FILLER PIPE |
4 | 17283181 | O-RING Ø37,77 MM SP=2,62 MM |
5 | 16677735 | HEXAGON BOLT M12X25 MM |
