F5CE9454C*A001
0432.038 REAR C.CASE COVER

Iveco/FPT REAR C.CASE COVER

Item Part number Description
1 504291010 FRONT C.CASE COVER
2 504240750 TIMINGGEAR HOUSIN
3 504242801 FLAT ENGINE GASKET
4 504092108 FLAT ENGINE GASKET
5 564530 COVER
6 504320425 FLAT ENGINE GASKET
7 504071685 PTO COVER
8 18137825 HEXAGON BOLT M6X16
9 16600224 HEXAGON BOLT M8X1,25X18 MM
10 504051236 THREADED PLUG DIAM=1/8"
11 504204989 OIL NOZZLE
12 16586625 HEXAGON BOLT M8X35 MM
13 4798845 SCREW
14 98401723 HEXAGON BOLT M8X1,25X12 MM
15 16673735 HEXAGON BOLT M8X25 MM
16 10300611 LOCK PLUG M14X1,5
17 4858608 SEAL GASKET dia.14x19,5x1,5
18 16586925 HEXAGON BOLT M8X50 MM
19 99435557 DOWEL PIN Ø8,5 MM
20 2992545 ADHESIVE/STICKER
