| Item |
Part number |
Description |
|
1 |
504208988 |
WATER MANIFOLD RIGHT |
|
2 |
504208989 |
WATER MANIFOLD LEFT |
|
3 |
504044298 |
WATER PIPE |
|
4 |
504049041 |
INTAKE ELBOW GASK. |
|
5 |
504096325 |
WATER PIPE |
|
6 |
16673735 |
HEXAGON BOLT M8X25 MM |
|
7 |
504067723 |
HEXAGON BOLT M8X1,25X60 MM |
|
8 |
504067722 |
HEXAGON BOLT M8X1,25X75 MM |
|
9 |
17289881 |
O-RING Ø50,3 MM SP=3,5 MM |
|
10 |
16673635 |
HEXAGON BOLT M8X1.25X20 |
|
11 |
16592424 |
HEXAGON BOLT M8X65 MM |
|
12 |
16690735 |
CYLIND-HEAD SCREW M8X30 MM |
|
13 |
17094824 |
WASHER Ø8,40X15 MM |
|
14 |
504044304 |
INTAKE ELBOW GASK. |
|
15 |
16992315 |
THREADED PLUG M14X1,5 |
|
16 |
99489018 |
SEAL GASKET Ø14X22 MM SP=1,5 MM |
