| Item |
Part number |
Description |
|
1 |
8017431 |
ELECTRIC MACHINE UCI 224 F 14 50-60HZ [up to 05-95] |
|
2 |
8104707 |
WIRE/CABLE |
|
3 |
16043124 |
SCREW M8X14 MM |
|
4 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
5 |
16614824 |
SCREW M16X50 |
|
6 |
17093174 |
WASHER Ø24X46X5,4 MM |
|
7 |
17039721 |
HEXAGON NUT M24 |
|
8 |
4929369 |
WASHER |
|
9 |
17494934 |
WASHER Ø10X18,1X2,2 MM |
|
10 |
16607524 |
HEXAGON BOLT M10X1,5X20 MM (8.8) |
|
11 |
17090174 |
SPRING WASHER Ø10X20 MM |
|
12 |
16692324 |
SOCKET-HEAD SCREW M10X35 MM |
|
13 |
17038921 |
NUT M16X2 |
|
14 |
8015167 |
SUPPORT |
|
15 |
16620624 |
SCREW M24X130 |
|
16 |
17092174 |
SPRING WASHER Ø16X32X3,4 |
|
17 |
17037931 |
HEXAGON NUT M8X1,25 |
|
18 |
16607824 |
HEXAGON BOLT M10X35 MM (8.8) |
|
19 |
16608024 |
HEXAGON BOLT M10X1,25X45 MM |
|
20 |
17710174 |
WASHER Ø6X11 MM |
|
21 |
17094714 |
WASHER Ø6,4X12 MM |
|
22 |
16605624 |
HEXAGON BOLT M8X25 MM (8.8) |
|
23 |
8020803 |
ELECTRIC MACHINE UCD 224 F 16 50-60HZ [from 05-95] |
|
24 |
8016784 |
RUBBER PAD |
|
25 |
17038121 |
HEXAGON NUT M10 |
|
26 |
16607624 |
SCREW M10X25 |
|
27 |
8010711 |
SPACING BAR |
|
32 |
8092769 |
KIT-GENERATOR Stamford |
|
33 |
8106738 |
EL.MACHINE VOLTAGE REGUL. Stamford |
