GE8045M08.00A61S
1050.003 ADDITIONAL MASSES

Iveco/FPT ADDITIONAL MASSES

Item Part number Description
1 583514 BUSH
2 4600329 CIRCLIP
3 4600367 PIN ASSY
4 4600375 SUPPORT ASSY
5 4600376 GEAR ASSY
6 4600377 WASHER
7 4600381 WASHER
8 4812465 CENTERING BUSH
9 11903814 SCREW CONNECTOR M10X1,25X19 MM
10 4600386 WASHER
11 4812938 OIL LINE
12 4605610 GEAR
13 4605612 COUPLER
15 4628982 BUSH
16 4667450 WASHER
17 4834331 SPAC.RING CYL.LIN.
18 4668200 WASHER
19 4599807 BUSH
20 4707674 CIRCLIP
21 4812932 GEAR ASSY
22 4770244 GEAR
23 4778867 SCREW
24 4788666 PIN
25 4789294 WASHER ASSY
26 10260160 SEAL GASKET Ø10X14 MM SP=1 MM
27 4789410 HUB ASSY
28 4792111 SUPPORT ASSY
29 10329910 PARALLEL PIN Ø3 MM
30 17089474 SPRING WASHER Ø8X16 MM SP=1,4 MM
31 14171170 PLUG
32 14323911 LOCK PLUG M10X1,25
33 16605524 HEXAGON BOLT M8X20 MM
34 16044521 HEXAGON BOLT M8X65 MM
35 4692384 BUSH
