GE8210SRI25.01R970
A29060010 SUBBASE FOR GENERATOR UNIT

Iveco/FPT SUBBASE FOR GENERATOR UNIT

Item Part number Description
1 8029746 TANK
2 8018418 FUEL TANK PLUG
3 8028532 FUEL LEVEL GAUGE
4 8028539 ELBOW COUPLING
5 8029748 THREADED PLUG
6 8029688 FUEL PIPES
7 8028524 THREADED UNION
8 16607524 HEXAGON BOLT M10X1,5X20 MM (8.8)
9 17090174 SPRING WASHER Ø10X20 MM
10 8029629 HOSE L=600 MM
11 8028778 FUEL LINE L=400 MM
12 8028602 RETAINER
13 8028527 PUMP
14 8012424 MAR. ENG. SUCTION PUMP
15 8028526 RETAINER COCK
16 8028519 PIPE SOCKET
17 8028522 PIPE SOCKET
18 8028541 PIPE SOCKET
19 16605624 HEXAGON BOLT M8X25 MM (8.8)
20 17037925 HEXAGON NUT M8X1,25
21 17098574 WASHER
22 10902633 HEXAGON BOLT M6X1X25 MM
23 17037821 HEXAGON NUT M6X1
24 17088874 WASHER
25 16603677 HEXAGON BOLT M6X16 MM
26 8029967 SWITCHGEAR
27 8029948 RETAINER
28 8029992 WIRE/CABLE
29 8029994 WIRE/CABLE
30 17315090 FASTENING BRACKET Ø14 MM
31 8028490 PIPE SOCKET
32 16981135 HEXAGON NUT M22
33 17088474 WASHER Ø6X12 MM
