| Item |
Part number |
Description |
|
1 |
8109500 |
WATER PIPE |
|
2 |
15004021 |
HEXAGON BOLT M10X1,25X25 MM |
|
3 |
17090274 |
WASHER Ø10X20 MM |
|
4 |
16605424 |
SCREW M8X16 MM (8.8) |
|
5 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
6 |
8110840 |
RETAINER |
|
7 |
14464281 |
O-RING Ø44 MM SP=3,53 MM |
|
8 |
8112495 |
CONNECTOR SLEEVE |
|
9 |
8109497 |
COVER |
|
10 |
4864082 |
BANJO BOLT M12X1,5X25 MM |
|
11 |
4858607 |
WASHER Ø12X17 MM SP=1,5 MM |
|
12 |
8014477 |
WATER PIPE |
|
13 |
4716260 |
FLAT ENGINE GASKET |
|
14 |
4816749 |
FLAT ENGINE GASKET |
|
15 |
8109498 |
WATER PIPE |
|
16 |
17088474 |
WASHER Ø6X12 MM |
|
17 |
16604124 |
HEXAGON BOLT M6X40 MM |
|
18 |
16692311 |
PLUG |
|
19 |
4858608 |
SEAL GASKET dia.14x19,5x1,5 |
|
20 |
8105608 |
GASKET |
|
21 |
16605524 |
HEXAGON BOLT M8X20 MM |
|
22 |
16691324 |
CYLIND-HEAD SCREW M8X60 MM |
|
23 |
16691224 |
CYLIND-HEAD SCREW M8X55 MM |
|
25 |
17101534 |
SPRING WASHER Ø8 MM |
