GE8281SRG75.10A80E
2820.011 IGNITION CONTROL

Iveco/FPT IGNITION CONTROL

Item Part number Description
1 4859822 INJ.PUMP DRIV.GEA
2 4686615 BUSH
3 4796588 COVER
4 4863493 FLAT ENGINE GASKET
5 4809614 INJECT.PUMP SPIND
6 98424000 SUPPORT ASSY
7 10519601 WASHER Ø8X17 MM
8 16043311 HEXAGON BOLT M8X18 MM
9 14348931 SCREW M10X1,25X25
10 17281481 O-RING Ø10,7 MM SP=2,6 MM
11 17293481 O-RING Ø177,4 MM SP=3,5 MM
12 17089974 SPRING WASHER Ø8X22X2,4MM
13 10269150 LOCK PLUG M6X1
14 16605424 SCREW M8X16 MM (8.8)
15 8021647 SUPPORT
16 8017838 PICK-UP
17 16689124 CYLIND-HEAD SCREW M6X16 MM
18 17088474 WASHER Ø6X12 MM
19 8020130 SHAFT
20 8020134 DRIVE BEARING
21 16867176 CIRCLIP Ø35X1,5 MM
22 17285081 O-RING Ø67,94 MM SP=2,62 MM
23 8020135 OIL RETAINER
24 8020133 COVER
25 8017842 IGNITION CONTROL DISC
26 8020132 WASHER
27 16744924 STUD M6X12X16
28 17037821 HEXAGON NUT M6X1
29 8021636 FLANGE
30 8021635 COVER
