GE8281SRG75.10A80E
3280.025 WATER FILTER
| Item | Part number | Description |
|---|---|---|
| 1 | 1901776 | WATER FILTER CARTRIDGE |
| 2 | 8023354 | SUPPORT |
| 3 | 61316100 | VALVE |
| 4 | 98429281 | SEAL GASKET Ø24X31 MM SP=1,5 MM |
| 5 | 4807730 | BREATHER CONN. |
| 6 | 8023911 | WATER PIPE |
| 7 | 8023910 | WATER PIPE |
| 8 | 16607624 | SCREW M10X25 |
| 9 | 17090174 | SPRING WASHER Ø10X20 MM |
| 10 | 4864083 | SCREW CONNECTOR M14X1,5X30 MM |
| 11 | 98474308 | SEAL GASKET Ø14X22 MM |
| 12 | 8024646 | O-RING Ø6 MM |
| 13 | 4623465 | FLANGED SOCKET |
