GE8281SRM44.30A60E
3280.001/01 WATER FILTER

Iveco/FPT WATER FILTER

Item Part number Description
1 8023354 SUPPORT
2 61316100 VALVE
3 4807730 BREATHER CONN.
4 1901776 WATER FILTER CARTRIDGE
5 17089474 SPRING WASHER Ø8X16 MM SP=1,4 MM
6 16605624 HEXAGON BOLT M8X25 MM (8.8)
7 17037931 HEXAGON NUT M8X1,25
8 4936558 RETAINER
9 17092174 SPRING WASHER Ø16X32X3,4
10 15980321 HEXAGON BOLT M16X1,5X25 MM
11 4623465 FLANGED SOCKET
12 98429281 SEAL GASKET Ø24X31 MM SP=1,5 MM
