| Item |
Part number |
Description |
|
1 |
16619124 |
SCREW M10X22 MM |
|
2 |
17494934 |
WASHER Ø10X18,1X2,2 MM |
|
3 |
16607924 |
HEXAGON BOLT M10X1,5X40 MM |
|
4 |
17090174 |
SPRING WASHER Ø10X20 MM |
|
5 |
504086679 |
ELECTRIC MACHINE |
|
6 |
16614824 |
SCREW M16X50 |
|
7 |
17038921 |
NUT M16X2 |
|
8 |
17092174 |
SPRING WASHER Ø16X32X3,4 |
|
9 |
17095724 |
WASHER Ø16 MM |
|
10 |
8016025 |
SPACING BAR |
|
11 |
16607734 |
HEXAGON BOLT M10X30 MM |
|
12 |
17038131 |
HEXAGON NUT M10 |
|
13 |
17090474 |
SPRING WASHER Ø10X27 MM SP=2,5 |
|
14 |
503111672 |
RUBBER LUG |
|
15 |
8106738 |
EL.MACHINE VOLTAGE REGUL. Stamford |
|
16 |
8092769 |
KIT-GENERATOR Stamford |
