GS8361SRi26.06A060
0710.021 INTAKE MANIFOLD
Item | Part number | Description |
---|---|---|
1 | 4726705 | INTAKE ELBOW ASSY |
2 | 500300885 | INTAKE ELBOW GASK. |
3 | 4577310 | THREADED PLUG |
4 | 4753563 | PLUG M10X1,5 |
5 | 10263360 | SEAL GASKET 20x26x1 |
6 | 10276401 | LOCK PLUG M24X1,5 |
7 | 10264560 | SEAL GASKET Ø24X32 MM SP=1,5 MM |
8 | 10520001 | WASHER Ø12X22 MM |
9 | 15541021 | HEXAGON BOLT M12X1,25X60 MM |
10 | 15541621 | HEXAGON BOLT M12X1,25X100 MM |
11 | 10260160 | SEAL GASKET Ø10X14 MM SP=1 MM |
12 | 13543421 | STUD M8X16 MM |
