N40ENTM25.10
2460.046 AIR - WATER HEAT EXCHANGER
| Item | Part number | Description |
|---|---|---|
| 1 | 8037891 | SUPPORT |
| 2 | 8036076 | AIR/WATER HEAT EXCHANGER ASSY |
| 3 | 8031755 | WATER PIPE |
| 4 | 17297081 | O-RING Ø88,26X5,33 MM |
| 5 | 16592424 | HEXAGON BOLT M8X65 MM |
| 6 | 16586925 | HEXAGON BOLT M8X50 MM |
| 7 | 16586624 | HEXAGON BOLT M8X35 MM |
| 8 | 16673635 | HEXAGON BOLT M8X1.25X20 |
| 9 | 16592224 | HEXAGON BOLT M8X55 MM |
| 10 | 16045521 | HEXAGON BOLT M8X115 MM |
| 11 | 17094914 | WASHER 8x16 |
