N60ENTF40.00
2460.042 AIR - WATER HEAT EXCHANGER
Item | Part number | Description |
---|---|---|
1 | 8033578 | AIR/WATER HEAT EXCHANGER ASSY |
2 | 8033847 | SUPPORT |
3 | 16588225 | HEXAGON BOLT M12X40 MM |
4 | 16590424 | HEXAGON BOLT m16x65MM |
5 | 16592225 | HEXAGON BOLT M8X55 MM |
6 | 16607024 | HEXAGON BOLT M8X120 MM |
7 | 17094914 | WASHER 8x16 |
8 | 17297081 | O-RING Ø88,26X5,33 MM |
9 | 16677735 | HEXAGON BOLT M12X25 MM |
10 | 8031755 | WATER PIPE |
