| Item |
Part number |
Description |
|
1 |
8016304 |
OIL/WATER HEAT EXCHANGER ASSY |
|
2 |
17090174 |
SPRING WASHER Ø10X20 MM |
|
3 |
8039731 |
CLIP |
|
4 |
8108735 |
OIL HOSE |
|
5 |
16605624 |
HEXAGON BOLT M8X25 MM (8.8) |
|
6 |
16605734 |
HEXAGON BOLT M8X30 MM |
|
7 |
17089474 |
SPRING WASHER Ø8X16 MM SP=1,4 MM |
|
8 |
17368024 |
STUD M10X25X30 |
|
9 |
4935465 |
PIPE SOCKET |
|
10 |
8108736 |
OIL HOSE |
|
11 |
17038131 |
HEXAGON NUT M10 |
|
12 |
8005929 |
FLEXPLATE |
|
13 |
17798374 |
SPRING WASHER Ø10,2X18,1 MM |
|
14 |
15970524 |
HEXAGON BOLT M10X1,25X20 |
|
15 |
8107173 |
PIPE SOCKET |
|
16 |
4858609 |
WASHER Ø16X22 MM SP=1,5 MM |
|
17 |
8105826 |
PIPE SOCKET |
|
18 |
10183317 |
LOCK PLUG M16X1,5 |
|
19 |
98474309 |
WASHER Ø16X24 MM SP=1,9 MM |
