| Item |
Part number |
Description |
|
1 |
8018324 |
AIR COMPRESSOR ASSY |
|
2 |
504050489 |
V-BELT |
|
3 |
504068024 |
PULLEY |
|
4 |
8037238 |
COMPRESSOR PULLEY |
|
5 |
17038131 |
HEXAGON NUT M10 |
|
6 |
17039221 |
NUT M18X1,5 |
|
7 |
16288424 |
HEXAGON BOLT M10X1,25X25 MM |
|
8 |
8037243 |
BELT TENSIONER |
|
9 |
504082643 |
HEXAGON BOLT |
|
10 |
16587125 |
HEXAGON BOLT M10X25 MM |
|
11 |
16598224 |
HEXAGON BOLT M8X90 MM |
|
12 |
16598325 |
HEXAGON BOLT M8X100 MM |
|
13 |
16593524 |
HEXAGON BOLT M12X110 MM |
|
14 |
504071584 |
SUPPORT |
|
15 |
98400783 |
FLAT ENGINE GASKET |
|
16 |
98418772 |
FLAT ENGINE GASKET |
|
17 |
8104980 |
OIL LINE |
|
18 |
18088493 |
CLIP |
|
19 |
504071635 |
RUBBER SLEEVE |
|
20 |
504078070 |
OIL LINE ASSY |
|
21 |
16600224 |
HEXAGON BOLT M8X1,25X18 MM |
|
22 |
504078071 |
OIL LINE ASSY |
|
23 |
18137825 |
HEXAGON BOLT M6X16 |
|
24 |
504071672 |
WATER PIPE |
|
25 |
8047649 |
WATER PIPE |
|
26 |
504071642 |
OIL LINE |
|
27 |
4893149 |
PIPE SOCKET |
|
28 |
4896491 |
ELBOW COUPLING M16X1,5 - M18X1,5 |
|
29 |
504043982 |
PIPE SOCKET |
|
30 |
99489016 |
SEAL GASKET Ø10X17 MM SP =1,5 |
|
31 |
4864080 |
SCREW CONNECTOR M10X1,25 |
|
32 |
4897881 |
ELBOW COUPLING |
|
33 |
98474315 |
GASKET |
|
34 |
17281881 |
O-RING DIA 17,12 SP 2,62 |
|
35 |
504078266 |
COMPRESSOR PULLEY |
|
36 |
504136474 |
CENTERING RING |
