PPVZ2883X*Q400
2710.123 OIL DIPSTICK
Item | Part number | Description |
---|---|---|
1 | 504069978 | COVER |
2 | 504055244 | SENSOR |
3 | 99489020 | SEAL GASKET Ø18X26 MM SP=1,5 MM |
4 | 16673535 | HEXAGON BOLT M8X16 MM |
5 | 504069933 | SEAL GASKET Ø19,18X2,46 MM |
6 | 16993315 | THREADED PLUG |
