PPVZ2883X*Q440
508301.000/03 ELECTRIC WIRING
| Item | Part number | Description |
|---|---|---|
| 1 | 504073582 | HOUSING ASSY |
| 2 | 504068224 | WIRE/CABLE |
| 3 | 504054794 | RELAY |
| 4 | 504080776 | FASTENING BRACKET |
| 5 | 504043559 | SET OF WIRING 4 |
| 6 | 504060466 | SET OF WIRING ZF |
| 7 | 504060467 | WIRE/CABLE EDC |
| 8 | 504064402 | WIRE/CABLE |
| 9 | 504055606 | WIRE/CABLE |
| 10 | 504056704 | WIRE/CABLE |
| 11 | 504056705 | WIRE/CABLE |
| 12 | 504056712 | WIRE/CABLE |
| 13 | 504056714 | WIRE/CABLE |
| 14 | 504060468 | WIRE/CABLE |
| 15 | 504061748 | RETAINER |
| 16 | 504097851 | FASTENING BRACKET |
| 17 | 504063139 | SUPPORT |
