| Item |
Part number |
Description |
|
1 |
504073722 |
OIL TANK ASSY |
|
2 |
17764593 |
CLIP Ø20/32 MM |
|
3 |
8025782 |
OIL HOSE |
|
4 |
8050314 |
OIL HOSE |
|
5 |
8050248 |
THREADED UNION |
|
6 |
4858609 |
WASHER Ø16X22 MM SP=1,5 MM |
|
7 |
8044263 |
OIL PUMP-STEERING |
|
8 |
98429282 |
SEAL GASKET Ø26X33 MM SP=1,5 MM |
|
9 |
8017989 |
THREADED UNION |
|
10 |
98474312 |
GASKET |
|
11 |
8050280 |
SWIVEL COUPLING |
|
12 |
98429224 |
SCREW CONNECTOR |
|
13 |
18088393 |
CLIP Ø16/25 MM |
|
14 |
8048921 |
OIL HOSE |
|
15 |
42547928 |
LOCK PLUG |
|
16 |
42546129 |
WASHER |
|
17 |
504243643 |
SPACING BAR |
|
18 |
504001047 |
HEXAGON BOLT M10X1.25X110 MM |
|
19 |
504104089 |
SPACING BAR |
