V08ENTM11.10C210
2030.284 FUEL LINES - fuel inlet from filter to head

Iveco/FPT FUEL LINES

Item Part number Description
1 16504114 ELBOW COUPLING M18X1,5
2 8042117 FUEL LINE
3 16501815 THREADED UNION
4 8042135 FUEL LINE
5 16500315 THREADED UNION M16X1,5 - M18X1,5
6 99489019 WASHER Ø16X24 MM SP=1,5 MM
7 17316490 CLIP
8 16605524 HEXAGON BOLT M8X20 MM
9 17089474 SPRING WASHER Ø8X16 MM SP=1,4 MM
10 8042623 CLIP
11 17037921 HEXAGON NUT M8X1,25
