V08ENTM12.10A210
2030.281 FUEL LINES
| Item | Part number | Description |
|---|---|---|
| 1 | 8042392 | FASTENING BRACKET |
| 2 | 16605424 | SCREW M8X16 MM (8.8) |
| 3 | 17089474 | SPRING WASHER Ø8X16 MM SP=1,4 MM |
| 4 | 8010502 | PIPE SOCKET M22X1,5 |
| 5 | 41217235 | HEXAGON NUT M22X1,5 |
| 6 | 8011138 | PIPE SOCKET 1/2''/M16X1,5 |
| 7 | 41217238 | NUT M18X1,5 |
