VECTOR8TE2.A002
3210.316 WATER LINES

Iveco/FPT WATER LINES

Item Part number Description
1 504208988 WATER MANIFOLD RIGHT
2 504208989 WATER MANIFOLD LEFT
3 504044298 WATER PIPE
4 504049041 INTAKE ELBOW GASK.
5 504096325 WATER PIPE
6 16673735 HEXAGON BOLT M8X25 MM
7 504067723 HEXAGON BOLT M8X1,25X60 MM
8 504067722 HEXAGON BOLT M8X1,25X75 MM
9 17289881 O-RING Ø50,3 MM SP=3,5 MM
10 16673635 HEXAGON BOLT M8X1.25X20
11 16592424 HEXAGON BOLT M8X65 MM
12 16690735 CYLIND-HEAD SCREW M8X30 MM
13 17094824 WASHER Ø8,40X15 MM
14 504044304 INTAKE ELBOW GASK.
15 16992315 THREADED PLUG M14X1,5
16 99489018 SEAL GASKET Ø14X22 MM SP=1,5 MM
